Panel Size:

• 2.1 metres (H) x 2.65 metres (W) with 1.8 plastic infill panels.

Concrete Block Size:

• 600mm x 220mm x 150mm weighing approximately 36kgs.

• Barbed Wire (1 or 3 rows)
• Extensions (2.4m high - Extra bracing required)
• Chicken Wire (Anti bill posting)
• View Windows (Public viewing)
• Personnel Gates (Approximately .9m wide)
• Warning Lights (As required)
• Safety Signs
• Chains and padlocks
• Gate latches
• Naming signage and corporate logos

Gates for access can be easily provided anywhere in the installation with the special gate clamps provided. For added security, the use of chains, padlocks and gate latches can also be provided.

What do you do for job sites that require edge protection for working at heights but scaffold isn't an option?

• Scaffold is impossible to erect
• Scaffold required for the entire job is too expensive

Our Solutions

• Our edge protection products can be installed around the upper floor without obstructing any lower roof works
• Frame carpenters are able to install roof trusses safely, without having to walk around top plates
• Our platform edge protection systems can be installed on existing houses for re-gutter/re-roof, even with minimum access around the house.
• Suitable for a wide range of construction; such as timber frame, steel frame and even concrete tilt slabs
• The edge protection products benefit all trades as we do not block any access to the site. Our products are secured to existing structures
• A cheaper alternative to ground up for fascia gutter and roof replacement.

The Guardrail Clamp On Edge Protection System provides valuable fall protection in those places where traditional systems fail to attach.

The ease of application allows for installations free from damage to the host materials and with the confidence of a strong handrail.

The Clamp-On System is used on the top of concrete parapet walls or the edge of cantilever slab floors and is adjustable from 100mm to 300mm to suit the thickness of walls or slabs.

Edge Safe Edge Protection is manufactured with the safety of carpenters in mind.

This system is easily installed and removed in a day, complementing the construction or maintenance process by providing safety with the speed of installation and dismantle.

In a time where construction and maintenance deadlines are imperative to cost effective building, we like to work in with the client to ensure nobody is left waiting for their safety systems.

The Edge Safe System installation compliments our Void Protection installation to provide a complete safety feature.

These edge protection applications can vary due to site conditions and building methods making them an adaptable solution to all your building needs. The combination of our experienced installers and the universal nature of these systems provide safety to any person accessing the roof.

Commercial metal roofers work effortlessly in and around the Guardrail Perimeter Edge Protection System, not being constrained by the dangers of an open edge.

The Guardrail Perimeter System fits all commonly used steel structures in the industrial and commercial sectors. The clamps are designed to attach to purlins, girts and fascia steel while not impeding the laying of roofing sheets.

ATF Height Safety stocks large quantities of this Guardrail Edge Protection System enabling us to cater for vast span distances. This allows the construction to continue free from the interruptions of multiple installation and removals to keep up with construction.

The Deck Set System may be used for edge protection, maintenance or as a barricade to designate a loading area, or a ‘NO GO’ zone.

In an environment where we are encouraged to use the likes of solar power, there is an increased need to access existing as well as new roof construction.

The Guardrail Re-Roof Edge Protection System allows for solar panel installation, roof maintenance and repair, air conditioning maintenance and the complete replacement of existing metal roofs.

Whether flat or pitched roofs, this application is suited to various metal roof profiles.

The function of Guardrail Re-Roof is to be able to slide one post at a time out of the way, so that roof sheets can be moved or replaced, while leaving the Guardrail System intact to provide protection for the roof worker.

Installation and dismantling requires a competence certificate for the safe installation/dismantling work practices, so there is no risk of falling.

Some site situations require an adaptable handrail system that can be used from the side as well as underneath if required. This is a system that has evolved into some very creative applications addressing unique site issues allowing the construction process to flow smoothly.

The Concrete Bolt-On Edge Protection System is used on tilt up panels whereby the roof and gutter extends over the panel. This system allows the laying of roof sheets, flashing and gutters to be completed while the fall protection stays in place.

A simple and effective perimeter system providing both visual and physical barriers for edge protection on commercial and industrial sites.

Differing from the Bolt-On System, the Guardrail Concrete & Brick Bolt Down Edge Protection System is fixed to a slab floor. This system also allows the laying of roof sheets flashing and gutters to be completed while the fall protection stays in place.

Used to provide edge protection on balconies allowing the early removal of external scaffolding.

This Clamp on System is also used on the top of concrete parapet walls and is adjustable from 100mm to 450mm.

What do you do for job sites that require the ability to work at heights but scaffold isn't an option?

• Scaffold is impossible to erect
• Scaffold required for the entire job is too expensive

Our Solutions

• Our height safety products can be installed around the upper floor without obstructing any lower roof works
• Frame carpenters are able to install roof trusses safely without having to walk around top plates
• Our platform height safety systems can be installed on existing houses for re-gutter/re-roof, even with minimum access around the house.
• Suitable for a wide range of construction; such as timber frame, steel frame and even concrete tilt slabs
• The product benefits all trades as we do not block any access to the site. Our products are secured to existing structures
• A cheaper alternative to ground up for fascia gutter and roof replacement.

The Guardrail Clamp On Edge Protection System provides valuable fall protection in those places where traditional systems fail to attach.

The ease of application allows for installations free from damage to the host materials and with the confidence of a strong handrail.

The Clamp-On System is used on the top of concrete parapet walls or the edge of cantilever slab floors and is adjustable from 100mm to 300mm to suit the thickness of walls or slabs.

Edge Safe is manufactured with the safety of carpenters in mind. Fitted to the lower storey stud wall rising up and out, it is designed not to impede the installation of pozzi struts, laying of flooring and second storey wall installations.

This edge protection system is easily installed and removed in a day, complementing the construction process by providing safety with the speed of installation and dismantle.

In a time where construction deadlines are imperative to cost effective building, we like to work with the client to ensure nobody is left waiting for their safety systems.

The Edge Safe System installation coincides with our void protection installation to provide a complete second storey safety feature.

Over Rafter

The Guardrail Over Rafter Edge Protection System is designed for the safety of roof tilers and fits to the rafter and penetrates the roof, just above and behind the fascia.

This system provides fall protection as well as the freedom to work in and around the tiling application. This edge protection can easily be dismantled at the completion of the tiling without leaving larger areas unfinished.

Not only a roof tiling necessity but one that provides optimum safety for fall protection.

Under Rafter

The Guardrail Under Rafter Edge Protection System is fitted to the rafters or studs.

The Guardrail comes under and around the fascia, not hindering the laying of the roof, whether it is tiles or metal.

Importantly, this application protects the worker and prevents damage to the fascia and gutter that has already been installed. It also allows the roof tiling to be fully completed without any interruption to the installation as the system comes from beneath the rafters.

The Pole Edge Protection System has been designed specifically for the re-roof market to allow restoration and repair work to be carried out unhindered. It is installed off the roof allowing totally clear access while providing full protection.
